Model No.: PET 901
The basis weight, substance or Grammage is obviously most fundamental property of paper board. All paper machines are designed to manufacture paper in a given basis weight range. Tighter the range and more efficient will be the machine but still it is common for paper manufacturers to seek methods to improve basis weight control. PET introduce Micro control based Motorised Basis Weight Valve to control the Grammage and save the time in maintaining GSM & grade change in pulp, paper industries.
§ Flange less V-notch ball valve with combination of Electro-Mechanical Actuator & Controller.
§ V-notch ball valve offers equal % characteristics for precise control.
§ Actuator with almost negligible backless.
§ Digital valve position indicator.
§ Easy to install and user friendly.
§ Can be hooked to DCS/QCS system.
§ Backed up by skilled service personal.
§ Strong support of prominent after sales service.
Technical Specification
Type of Construction : “V” notch shear control valve
Size : 80mm to 200mm
End Connection : Flange less
Body Material : SS316
Characteristic : Equal Percentage
Pressure Drop : 10% of Inlet Pressure
Actuator : Aluminium
Temperature : Ambient
Opening Time : as per valve size
Resolution Step : 15,000-35,000
Output Torque : 200Nm-500Nm (as per valve size)
Gear Ratio : 1:150 (min.), 1:500 (max.)
Feedback Output : 2K ohms
AC Supply : 220V/50Hz
